minimax s 45n
(512) 931-1962
Scie à ruban professionnelle, robuste, de haute précision pour les menuisiers et les artisans exigeants.
Avantages
-
Solidity and sturdiness
Very thick, cast iron wheels, as well as the worktable, running on sealed for life ball bearings. -
Safety first
Total safety machining with telescopic protections with rackwork to the blade. -
Perfect results
A perfect cut result is assured by the top and bottom high precision blade guides. Practical machines suitable also to perform straight and tilted cuts on wood, plastic and aluminum.
Données techniques
| s 45 n | ||
| Dimensions table d'usinage | 520 x 600 | mm |
| Diamètre volants en fonte | 450 | mm |
| Hauteur maxi de coupe | 300 | mm |
| Largeur maxi de coupe | 440 | mm |
| Inclinaison table d'usinage | 0° ÷ 20° | |
| Puissance moteurs triphasés | 3 (3,6) kW - 50 (60) Hz |
media
-
Presentation of the s 45 n Minimax band saw - Presentazione della sega a nastro s 45 n
-
Band Saw blade sharpening and setting - Stradatura e affilatura lama sega a nastro
-
Change band saw blade on the s 45 n - Cambio lama sega a nastro su s 45 n
-
Tips using bandsaw - Consigli utilizzo sega a nastro
