stefani s
(512) 931-1962
stefani s is a single-sided edge bander designed for medium- and large-scale industries, standing out for its high processing quality and maximum efficiency.
It is ideal for edgebanding straight panels, softforming panels, and doors, even with delicate edges and state-of-the-art materials.
stefani s can be integrated into flexible edgebanding cells and production lines.
It is ideal for edgebanding straight panels, softforming panels, and doors, even with delicate edges and state-of-the-art materials.
stefani s can be integrated into flexible edgebanding cells and production lines.
Advantages
-
FLEXIBILITY
Different gluing technologies are always available: from the use of EVA and/or PUR glue to AirFusion+ technology for a zero-joint finish, and the Glue Switch system for machine setup with no downtime. -
MODULARITY
stefani s is an edgebander that can be tailor-made to meet the specific needs of each customer.
It can be customized for different panel processing requirements, whether for straight panels or soft-formed panels.
The most efficient solution for every need. -
INTEGRATION
stefani s can be integrated into an edgebanding cell (stefani cell) with various solutions and levels of automation for both loading and unloading, as well as the panel return. It can also be integrated into an edgebanding line (stefani rocket) for complete and efficient solutions. -
FAST AND SIMPLE MANAGEMENT
The eye-M console and the Maestro active interface software, which has been unified across all SCM technologies and capable of interfacing with line supervision software, provide the operator with an efficient and intuitive working experience.
Technical data
|
Max working speed
|
m/min
|
25 (30 opt)
|
|
Coil edge thickness
|
mm
|
0.3-3
|
|
Pre-cut strip thickness
|
mm
|
0.4-1
|
|
Solid wood thickness
|
mm
|
25
|
|
Panel thickness
|
mm
|
10 – 60 (80 opt)
|
|
PANEL DIMENSIONS WITH COIL EDGE
|
|
|
|
Min/max panel length
|
mm
|
135 (125 opt)-3200
|
|
Min/max panel width
|
mm
|
95 (55 opt)-1200
|
|
Pneumatic system
|
MPa
|
6
|
|
Technology for edge application
|
|
EVA, PUR, EVA+PUR
AirFusion+
|
|
TYPE OF EDGE
|
EXAMPLE OF APPLICATION
|
MAX THICKNESS
|
|
Paper
|
Raw / prepainted
|
0,6 mm
|
|
Plastic in coil
|
ABS, PVC, PP (with/without film)
PMMA (polished or rough to polish/smooth)
|
3 mm
|
|
Alluminium
|
Shine/ Satin
|
3 mm
|
|
Pre-cut strips
|
Veneer, PC, Unicolor
|
1 mm
|
|
Solid wood
|
Raw / polished / drawn
|
25 mm
|
